Rebarrelling at home

Reply

Old 02-07-2014, 10:08 AM
  #1
Spike
Thread Starter

Join Date: Jun 2013
Posts: 64
Default Rebarrelling at home

I read an article where a guy bought a rifle in say 204 (i don't remember) and bought another barrel in 22-250 and separate bolts to go with it. He shot his 204 3 different times and removed the barrel between each shot and shot a .404 group. Then switched the 22-250 barrel out and shot almost the exact same group 1" high and 1" left removing the barrel again between shots. How would you go about doing this? It's a dang good idea, but he had a custom kelby 700 action with shillen barrels (which I can't afford either) and I want to use a howa 204 factory gun and just buy a spare bolt and barrel so I can do the same thing.
Attached Thumbnails Rebarrelling at home-image.jpg
00possum is offline
Reply With Quote
Old 02-07-2014, 10:09 AM
  #2
Spike
Thread Starter

Join Date: Jun 2013
Posts: 64
Default

Here are some pics of the article
Attached Thumbnails Rebarrelling at home-image.jpg
00possum is offline
Reply With Quote
Old 02-08-2014, 03:55 PM
  #3
Nontypical Buck

Join Date: Feb 2003
Location: Eastern wv
Posts: 2,553
Default

Barrel vice, action wrench, go and no go gauges for each caliber.
RR
Ridge Runner is offline
Reply With Quote
Old 02-12-2014, 05:47 PM
  #4
Nontypical Buck

Nomercy448's Avatar

Join Date: Oct 2009
Location: Kansas
Posts: 3,377
Default

Read up on "switch barrel" bench rest rigs. There are guys that have modified Rem 700's and Savages (basically pin the barrel nut to the barrel) with flats on the muzzle end of the barrel to let them wrench on and off the different barrels. Nice part of doing it with a Savage is that you don't need a complete bolt ($200ish to do it with a Remington where you need an entire bolt), you just need a bolt head. With a Savage, you can either pin the barrel nut, then torque the barrel/barrel nut onto the action from the muzzle without removing the action from the stock, OR, you can leave everything alone, pull it from the stock, pull the barrel, and replace it. All you need is a Savage barrel nut wrench and a set of go and no-go gauges to set the headspace.

The difference in this and doing your own barrel installs is that the headspace in the barrels has to be set, then the barrels can be removed and replaced at will, just by monitoring the witness marks, or torque setting. The challenge with buying a new barrel and doing your own barrel job is that, for other than "barrel nut" style rifles like Savage or Mossbergs now, you'll need a lathe to set the headspace, or get the chamber cut shallow then hand ream it (which can be hit or miss, depending on your technical ability). I had a Rem 700 switch barrel rig in college. Flats on the muzzle and a custom wrench. I had gunsmiths install the barrels the first time to headspace properly, then make witness marks on the bottom of the barrel to match the action mark and note the torque. Then I could remove it and replace it myself.

Savages are super easy to DIY, but it does require that you remove the stock, unless you pin the barrel nut, then it basically behaves just like any other threaded barrel.
